U-bot Omnidirectional Stacker Robot
- U1045
- U1060
- U1080
The U-bot Omnidirectional Stacker Robot is designed with a compact U-shaped chassis, minimizing aisle space requirements and significantly improving storage density. With exceptional maneuverability in narrow aisles, precise positioning, and flexible deployment, U-bot enables cost-effective high-density storage across various industries. Its seamless integration with AMRs, robotic arms, and other automation equipment further enhances sorting, picking, and inbound/outbound operations.
- - Lifting Height: 0–8m
- - Minimum Turning Radius: 1,370mm
- - Rated Load Capacity: 1,000kg
- - Minimum Aisle Width: 2,100mm
01Technological Innovations
01
Innovative U-shaped Design
Prevents cargo from tilting or slipping during handling.
02
High-Precision Positioning
Dual-laser SLAM navigation combined with QR codes and reflectors for reliable positioning.
03
Intelligent Perception
Equipped with a 3D depth camera for automatic pallet detection and deviation correction.
04
Omnidirectional Mobility
Featuring a double rudder wheel chassis¹ for faster, more stable, 360° maneuverability.
05
Stable Lifting
Imported channel steel guide rails ensure safe lifting up to 8m with zero load loss below 6m.
06
Enhanced Forward Reach
Rack & pinion drive system² provides 100% increased forward extension speed compared to conventional designs.
¹ Double Rudder Wheel: Dual steering wheels improve rotational agility and stability for precise movements in confined spaces.
² Rack & Pinion Drive: A mechanical drive combining a gear rack and pinion gear to achieve fast, accurate linear motion with high durability and driving force.
02Product Value
- Smarter Design
- Innovative U-frame enhances operational safety and handling efficiency.
- Higher Efficiency
- Boosts handling and picking speeds by 2–3 times compared to traditional solutions.
- Increased Density
- Achieves 30%–500% higher storage density, maximizing warehouse utilization.
- Advanced Intelligence
- Adapts to complex storage and picking scenarios for superior automation performance.
Comparison Table
| Features | Manual + Forklift | Counterbalance AGV | U-bot Omnidirectional Stacker |
|---|---|---|---|
| Travel Mode | Large turning radius, manual | Bidirectional driving | 360° omnidirectional maneuvering |
| Storage Density | Low | Low | High-density storage |
| Overall Efficiency | Low | Moderate | 40%+ improvement |
| Safety | Low | Medium | High safety standards |
U-bot 전방향 스태커 로봇 기술 사양
| Type / Item | U1045 | U1060 | U1080 |
|---|---|---|---|
| Size (mm) | 2198 × 1784 × 2100 | 2198 × 1820 × 2685 | 2198 × 1820 × 3465 |
| Rated Load (kg) | 1000 | 1000 | 1000 |
| Net Weight (kg) | 3000 | 3300 | 3500 |
| Lifting Height (mm) | 4500 | 6000 | 8000 |
| Pallet Size (mm) | 1000–1200 × 800–1200 | 1000–1200 × 800–1200 | 1000–1200 × 800–1200 |
| Max Travel Speed (m/s) | 1.5 | 1.5 | 1.5 |
| Min Turning Radius (mm) | 1370 | 1370 | 1380 |
| Min Aisle Width (mm) | 2100 | 2140 | 2140 |
| Positioning Method | Dual-laser SLAM Hybrid | Dual-laser SLAM Hybrid | Dual-laser SLAM Hybrid |
| Positioning Accuracy (mm) | ±10 | ±10 | ±10 |
| Lifting Speed (m/s) | 0.25 / 0.20 | 0.25 / 0.15 | 0.25 / 0.15 |
| Lowering Speed (m/s) | 0.20 / 0.20 | 0.20 / 0.20 | 0.20 / 0.20 |
| Max Forward Reach Speed (m/s) | 0.30 | 0.20 | 0.20 |
| Battery Voltage & Capacity | 48V / 210Ah | 48V / 210Ah | 48V / 210Ah |
| Operating Time (hrs) | 6–8 | 6–8 | 6–8 |
| Full Charge Time (hrs) | 2–3 | 2–3 | 2–3 |
| Operating Temperature (°C) | -10~45 | -10~45 | -10~45 |
| Battery Type | Lithium Iron Phosphate | Lithium Iron Phosphate | Lithium Iron Phosphate |
